CRIB PID calculator (using "TSrim" -- SRIM on ROOT)
Ion List
Input as many ions as you want here ↓↓↓
Format:
A␣Element␣Q+␣N
N = 0, 1, 2
: Display Color (See examples)
Examples:
13 C 6 1 (⇔
13
C
6+
N=1: blue
, primary beam)
13 N 7 2 (⇔
13
N
7+
N=2: red
, secondary beam)
14 N 7 0 (⇔
14
N
7+
N=0: black
, contaminant)
13 C 6 1 13 N 7 2 14 N 7 0 12 C 6 0 14 N 5 0 12 C 5 0 13 N 6 2 13 C 5 1 4 He 2 0
Basic Setting (F2 E-TOF & F3 TOF-TOF)
Beam-line Setup
F1
Brho (Tm)
Degrader material
Mylar
Al
Degrader thickness (um)
F2
PPAC Window thickness (um)
SSD thickness (um)
F3
PPACs Window thickness (um)
Distance between two PPACs (mm)
Display Options
Common
RF period (ns)
F2
T_RF offset (ns)
T_RF range min. & max. (ns)
E range min. & max. (MeV)
F3
T_RF offset (ns)
T_PPAC offset (ns)
T_RF range min. & max. (ns)
T_PPAC range min. & max. (ns)
Select trigger
PPAC a
PPAC b
Common
Swap X & Y axes
Advanced setting (F3 E-TOF with gas target)
Beam-line Setup
F3
Target window material
Havar
Mylar
Kapton
Target window thickness (um)
Target gas material
4HE 90% + CO2 10%
4He
Ar
Target length (mm, window to SSD)
Target pressure (Torr)
SSD dead layer thickness (um)
SSD Thickness (um)
Display Options
F3
E range in. & max. at F3 (MeV)
Examples
